Custom litz wire 2-13000 Strands Copper Stranding Wire for Transformer
Our company offers a variety of custom litz wire solutions to meet your specific needs. We offer single wire sizes ranging from 0.025 mm to 0.5 mm, with strand counts ranging from single to 13,000 strands.
In addition to stranded wire, we also offer various types of stranded wire with cover, including nylon served litz wire, taped litz wire, also flat nylon severed and taped litz wire.
Our products are designed to meet the unique needs of your application, ensuring optimal performance and efficiency. With an emphasis on quality and customization, we work closely with our customers to provide litz wire solutions that perfectly fit their systems. Trust us to tailor the ideal litz wire to your specifications and ensure the success of your project.
Product Specifications
| Attribute | Value |
| Diameter | 0.071mm |
| Temperature | 155 |
| Certification | IEC/NEMA/JIS/RoHS/ISO |
| Conductor | Copper |
| Strands | 250 |
| Breakdown voltage | 1300 |
| Insulation | UEW |
Technical Specifications
| Item | Technical requests | Test value 1 | Test value 2 |
| Conductor Diameter (mm) | 0.076-0.084 | 0.079 | 0.080 |
| Single wire diameter (mm) | 0.071±0.003 | 0.068 | 0.070 |
| O.D. (mm) | Max. 1.85 | 1.57 | 1.68 |
| Resistance Ω/m (20℃) | Max. 0.01196 | 0.01815 | 0.01812 |
| Breakdown Voltage V | 950 | 3100 | 3000 |
| Pitch mm | 29± 5 | √ | √ |
| No. of strands | 250 | √ | √ |
Explore the endless possibilities of our natural silk-covered litz wire and experience the extraordinary experience of working with a trusted industry leader. Contact us today to discuss your needs and let us create the perfect wire solution for your next project.
